Time-based deployments with Flux Operator

Update your Kubernetes workloads based on schedules with Flux Operator
By Matheus Pimenta & Stefan Prodan |
Tags:

We are thrilled to announce time-based deployments, a feature long-awaited by Flux users, in Flux Operator v0.23.0!

Organizations using Flux for GitOps deployments frequently require sophisticated control over when changes are applied to production systems, particularly in regulated industries or critical business environments. Key requirements include adhering to Change Advisory Board (CAB) approval windows, enforcing “No Deploy Fridays” policies, and restricting deployments during peak business hours to ensure service stability.

Maintenance windows become critical when managing helm upgrades, where teams need to skip reconciliation unless the current time falls within a specified interval. In regulated environments like medical device companies, automated deployments must be controlled to prevent unexpected disruptions during critical operational periods. Large telecommunications providers and ISVs managing multiple client clusters need gating mechanisms to control application rollouts, allowing tenants to consume platform updates when ready.

In this post, we show how to use time-based deployment with Flux Operator ResourceSets.

How it works

The Flux Operator ResourceSet API allows defining bundles of Flux objects by templating a set of resources with inputs provided by the ResourceSetInputProvider API.

The ResourceSetInputProvider API allows pulling inputs from external sources, such as GitHub pull requests, branches and tags. For example, on the reconciliation of a ResourceSetInputProvider of type GitHubTag, the operator will list the tags of a GitHub repository, filter them according to a semver range, and export a set of inputs for each matching tag in the ResourceSetInputProvider .status.exportedInputs field. For example:

status:
  exportedInputs:
  - id: "48955639"
    tag: "6.0.4"
    sha: 11cf36d83818e64aaa60d523ab6438258ebb6009

Starting with Flux Operator v0.23.0, the ResourceSetInputProvider API now has the field .spec.schedule, which allows defining a cron-based schedule for the reconciliation of the ResourceSetInputProvider. For example:

spec:
  schedule:
    # Every day-of-week from Monday through Thursday
    # between 10:00 to 16:00
    - cron: "0 10 * * 1-4"
      timeZone: "Europe/London"
      window: "6h"
    # Every Friday from 10:00 to 13:00
    - cron: "0 10 * * 5"
      timeZone: "Europe/London"
      window: "3h"

With this configuration, reconciliations of the ResourceSetInputProvider object would only be allowed to run within the specified time windows. When the window is active, the reconciliation happens normally, according to the interval defined in the fluxcd.controlplane.io/reconcileEvery annotation.

A complete example

  • Define a ResourceSetInputProvider: This provider will scan a Git branch or tag for changes and export the commit SHA as an input.
  • Configure schedule: The provider will have a reconciliation schedule that defines when it should check for changes in the Git repository.
  • Define a ResourceSet: The ResourceSet will use the inputs from the provider to create a GitRepository and Kustomization that deploys the application at the specified commit SHA.

ResourceSetInputProvider Definition

Assuming the Kubernetes deployment manifests for an application are stored in a Git repository, you can define a input provider that scans a branch for changes and exports the commit SHA:

apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSetInputProvider
metadata:
  name: my-app-main
  namespace: apps
  labels:
    app.kubernetes.io/name: my-app
  annotations:
    fluxcd.controlplane.io/reconcileEvery: "10m"
    fluxcd.controlplane.io/reconcileTimeout: "1m"
spec:
  schedule:
    - cron: "0 8 * * 1-5"
      timeZone: "Europe/London"
      window: 8h
  type: GitHubBranch # or GitLabBranch
  url: https://github.com/my-org/my-app
  secretRef:
    name: gh-app-auth
  filter:
    includeBranch: "^main$"
  defaultValues:
    env: "production"

For when Git tags are used to version the application, you can define an input provider that scans the Git tags and exports the latest tag according to a semantic versioning:

apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSetInputProvider
metadata:
  name: my-app-release
  namespace: apps
  labels:
    app.kubernetes.io/name: my-app
  annotations:
    fluxcd.controlplane.io/reconcileEvery: "10m"
    fluxcd.controlplane.io/reconcileTimeout: "1m"
spec:
  schedule:
    - cron: "0 8 * * 1-5"
      timeZone: "Europe/London"
      window: 8h
  type: GitHubTag # or GitLabTag
  url: https://github.com/my-org/my-app
  secretRef:
    name: gh-auth
  filter:
    semver: ">=1.0.0"
    limit: 1

ResourceSet Definition

The exported inputs can then be used in a ResourceSet to deploy the application using the commit SHA from the input provider:

apiVersion: fluxcd.controlplane.io/v1
kind: ResourceSet
metadata:
  name: my-app
  namespace: apps
spec:
  inputsFrom:
    - kind: ResourceSetInputProvider
      selector:
        matchLabels:
          app.kubernetes.io/name: my-app
  resources:
    - apiVersion: source.toolkit.fluxcd.io/v1
      kind: GitRepository
      metadata:
        name: my-app
        namespace: << inputs.provider.namespace >>
      spec:
        interval: 12h
        url: https://github.com/my-org/my-app
        ref:
          commit: << inputs.sha >>
        secretRef:
          name: gh-auth
        sparseCheckout:
          - deploy
    - apiVersion: kustomize.toolkit.fluxcd.io/v1
      kind: Kustomization
      metadata:
        name: my-app
        namespace: << inputs.provider.namespace >>
      spec:
        interval: 30m
        retryInterval: 5m
        prune: true
        wait: true
        timeout: 5m
        sourceRef:
          kind: GitRepository
          name: my-app
        path: deploy/<< inputs.env >>

When the ResourceSetInputProvider runs according to its schedule, if it finds a new commit, the ResourceSet will be automatically updated with the new commit SHA which will trigger an application deployment for the new version.
